| Type of Product | Deep Groove Ball Bearing |
| Material | High Carbon Chrome Steel |
| Model No | 6913C3 |
| Weight | 0.206 Kg |
Type of Product |
Deep Groove Ball Bearing |
Material |
High Carbon Chrome Steel |
Model No |
6913C3 |
Weight |
0.206 Kg |
Series |
6900 Series |
Limiting Speed (Oil) |
8,200 RPM |
Limiting Speed (Grease) |
7,000 RPM |
Bearing Type |
Single Row Deep Groove Ball Bearing |
Bore Type |
Round |
Cage Type |
Pressed |
Width (B) |
13 mm |
Bore Diameter (d) |
65 mm |
Fatigue Load Limit |
1.07 kN |
Precision |
ISO Class 0 |
Country of Origin |
India |
Cage Material |
Steel |
Dynamic Load Rating |
19.3 kN |
Static Load Rating |
16.1 kN |
Ball Material |
Steel |
Seal Type |
Open |
Operating Temperature Range |
-40 ºC to 120 ºC |
Enclosure |
Open |
Radial Internal Clearance |
C3 |
Name of Manufacturer/Packer/Importer |
Mechanical Solutions |
Outside Diameter (D) |
90 mm |
Configuration |
Single Row |
Contact Type |
Radial |
Minimum Shaft Shoulder Diameter (da min) |
70 mm |
Maximum Fillet Radius (ra max) |
1 mm |
Minimum Chamfer Radius (r) |
1 mm |
Maximum Housing Shoulder Diameter (Da max) |
85 mm |
