| Type of Product | Deep Groove Ball Bearing |
| Material | High Carbon Chrome Steel |
| Model No | 6930C3 |
| Weight | 3.30 Kg |
Type of Product |
Deep Groove Ball Bearing |
Material |
High Carbon Chrome Steel |
Model No |
6930C3 |
Weight |
3.30 Kg |
Series |
6900 Series |
Limiting Speed (Oil) |
3300 RPM |
Limiting Speed (Grease) |
2800 RPM |
Bearing Type |
Single Row Deep Groove Ball Bearing |
Bore Type |
Round |
Cage Type |
Pressed |
Width (B) |
28 mm |
Bore Diameter (d) |
150 mm |
Precision |
ISO Class 0 |
Country of Origin |
India |
Cage Material |
Steel |
Dynamic Load Rating |
111 kN |
Static Load Rating |
116 kN |
Ball Material |
Steel |
Seal Type |
Open |
Operating Temperature Range |
-40 ºC to 120 ºC |
Enclosure |
Open |
Radial Internal Clearance |
C3 |
Name of Manufacturer/Packer/Importer |
Mechanical Solutions |
Outside Diameter (D) |
210 mm |
Configuration |
Single Row |
Contact Type |
Radial |
Minimum Shaft Shoulder Diameter (da min) |
159 mm |
Maximum Fillet Radius (ra max) |
1.5 mm |
Minimum Chamfer Radius (r) |
1.5 mm |
Maximum Housing Shoulder Diameter (Da max) |
201 mm |
