| Type of Product | Digimatic Depth Gage |
| Resolution (mm) | 0.0005 mm |
| Model No | 547-258A |
| Range (Inch) | 0-8 Inch |
Type of Product |
Digimatic Depth Gage |
Resolution (mm) |
0.0005 mm |
Model No |
547-258A |
Range (Inch) |
0-8 Inch |
Accuracy |
±0.005 mm |
Range |
0-200 mm |
Resolution |
0.00002 Inch |
Country of Origin |
JAPAN |
Scale |
Capacitance type ABSOLUTE linear encoder |
Type |
ABSOLUTE |
Repeatability (mm) |
0.01 mm |
Output Type |
SPC Data Output |
Maximum Response Speed |
Unlimited |
Stroke |
12.7 mm |
Name of Manufacturer/Packer/Importer |
Mitutoyo |
Accuracy (Inch) |
±0.001 Inch |
Base Size |
100x10 mm |
Protection |
IP67: High Level Of Protection Against Dust And Liquid Ingress |
Contact Point |
Carbide ball |
Measuring Force |
≤1.5N |
