| Type of Product | Dial Depth Gauge |
| Model No | DM-210 |
| Country of Origin | Japan |
| Monotaro ID | 1997432 |
Type of Product |
Dial Depth Gauge |
Model No |
DM-210 |
Country of Origin |
Japan |
Monotaro ID |
1997432 |
RoHS Directive |
Correspondence |
Type |
Needle-shaped probe type |
Measuring Force (N) |
1.4 or less |
Overall Length (mm) |
98.9 |
Minimum Reading (mm) |
0.01 |
Import Country |
Direct Import from Japan |
Trusco Part No. |
102-8669 |
Measuring Ranges |
10 mm |
Name of Manufacturer/Packer/Importer |
Teclock Co., Ltd. |
Mass (g) |
240 |
Hole diameter (mm) |
2.5 |
Probe Shape (mm) |
Acicular |
How to Use |
Place the bottom of the base against the measurement origin (zero point) and rotate the outer frame to align it to 0. (The outer frame is fixed in place with a clamp.) Use the hour and minute hands to read how far the contact point protrudes from that position. |
Accuracy (μm) |
12 |
