| Type of Product | Dial Depth Gauge |
| Model No | DM-283 |
| Country of Origin | Japan |
| Monotaro ID | 1997484 |
Type of Product |
Dial Depth Gauge |
Model No |
DM-283 |
Country of Origin |
Japan |
Monotaro ID |
1997484 |
RoHS Directive |
Correspondence |
Measuring Force (N) |
1.4 or less |
Overall Length (mm) |
98.9 |
Minimum Reading (mm) |
0.01 |
Import Country |
Direct Import from Japan |
Measuring Ranges |
10 mm |
Name of Manufacturer/Packer/Importer |
Teclock Co., Ltd. |
Mass (g) |
185 |
Specifications |
Dial depth gauge (round base type) with a circular base. |
Probe Shape (mm) |
Φ3.2 steel ball |
How to Use |
Place the bottom of the base against the measurement origin (zero point) and rotate the outer frame to align it to 0. (The outer frame is fixed in place with a clamp.) Use the hour and minute hands to read how far the contact point protrudes from that position. |
