| Model No | ID-F0550NX+06AGL011+IT-020U |
| Type of Product | Digimatic Indicator + Input Tool (USB) Set |
| Monotaro ID | 37795235 |
| Measuring Force (N) | MPL: 2.3 or lower |
Model No |
ID-F0550NX+06AGL011+IT-020U |
Type of Product |
Digimatic Indicator + Input Tool (USB) Set |
Monotaro ID |
37795235 |
Measuring Force (N) |
MPL: 2.3 or lower |
Power Supply |
External Power Supply (Ac Adapter 5.9V2A) |
Position Detection Method |
Capacitive Absolute Linear Encoder |
Maximum Response Speed |
Unlimited |
Return error (mm) |
(MPE)EMPE：0.002 |
Back Plate Specification |
Flat |
Repeatability (mm) |
(MPE)EMPE：0.002 mm |
Indication Errors |
[Partial measurement range] (MPE)EMPE: 0.004 mm |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Mitutoyo Corporation |
Minimum Reading (mm) |
0.0005, 0.001, 0.01 mm |
Stem Diameter (mm) |
8 |
Measuring_Range |
50.8 mm |
Specifications |
Measurement posture: horizontal horizontal posture |
Pack of |
1 Kit |
Indication Error for The Entire Measuring Range (mm) |
(MPE)EMPE：0.004 |
