| Model No | 543-736B |
| Type of Product | Digimatic Indicator |
| Measurement Range (mm) | 0-50.8 mm |
| Resolution (mm) | 0.01 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
543-736B |
Type of Product |
Digimatic Indicator |
Measurement Range (mm) |
0-50.8 mm |
Resolution (mm) |
0.01 mm |
Range (Inch) |
0-2 Inch |
Accuracy |
±0.04 mm |
Resolution |
0.0005 Inch |
Repeatability |
0.0005 Inch |
Repeatability (mm) |
0.01 mm |
Protection |
IP42 |
Series |
ID-CX |
Country of Origin |
JAPAN |
Type |
ABSOLUTE Flat Back |
Name of Manufacturer/Packer/Importer |
Mitutoyo |
Accuracy (Inch) |
0.0015 Inch |
Stem Diameter |
8 mm |
Hysteresis |
0.02 mm (0.001 Inch) |
Scale |
Capacitance type, ABSOLUTE linear encoder |
Contact Point |
Carbide ball, thread : M 2.5x0.45 mm |
