| Model No | 543-706 |
| Type of Product | Digimatic Indicator |
| Measurement Range (mm) | 0-12.7 mm |
| Resolution (mm) | 0.00005/0.001/0.01 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
543-706 |
Type of Product |
Digimatic Indicator |
Measurement Range (mm) |
0-12.7 mm |
Resolution (mm) |
0.00005/0.001/0.01 mm |
Range (Inch) |
0-0.5 Inch |
Accuracy |
±0.003 mm |
Resolution |
0.00002/0.00005/0.0001/0.0005 Inch |
Repeatability |
0.00008 Inch |
Repeatability (mm) |
0.002 mm |
Protection |
IP42 Dust/liquid |
Series |
ID-CX |
Country of Origin |
JAPAN |
Maximum Response Speed |
Unlimited |
Type |
ABSOLUTE Lug Back |
Name of Manufacturer/Packer/Importer |
Mitutoyo |
Accuracy (Inch) |
0.00012 Inch |
Stem Diameter |
8 mm |
Hysteresis |
0.002 mm (0.00008 Inch) |
Scale |
Electrostatic capacitance type absolute linear encoder |
Contact Point |
Carbide ball, M2.5×0.45 thread |
