| Model No | 543-570 |
| Type of Product | Digimatic Indicator |
| Measurement Range (mm) | 0-12.7 mm |
| Resolution (mm) | 0.01 mm |
Model No |
543-570 |
Type of Product |
Digimatic Indicator |
Measurement Range (mm) |
0-12.7 mm |
Resolution (mm) |
0.01 mm |
Accuracy |
±0.02 mm |
Repeatability (mm) |
0.01 mm |
Protection |
IP66 Dust/liquid |
Series |
ID-N/B |
Country of Origin |
JAPAN |
Maximum Response Speed |
Unlimited |
Type |
ABSOLUTE |
Name of Manufacturer/Packer/Importer |
Mitutoyo |
Measuring Force |
2.5N or less |
Stem Diameter |
8 mm |
Hysteresis |
0.02 mm |
Scale |
Capacitance type, ABSOLUTE linear encoder |
Contact Point |
Carbide ball, M2.5×0.45 thread |
