| Model No | 543-721B |
| Type of Product | Digimatic Indicator |
| Measurement Range (mm) | 0-25 mm |
| Resolution (mm) | 0.01/0.001/0.0005 mm |
Model No |
543-721B |
Type of Product |
Digimatic Indicator |
Measurement Range (mm) |
0-25 mm |
Resolution (mm) |
0.01/0.001/0.0005 mm |
Range (Inch) |
0-1 Inch |
Accuracy |
±0.003 mm |
Resolution |
0.0005/0.0001/0.00005/0.00002 Inch |
Repeatability |
0.0001 Inch |
Repeatability (mm) |
0.002 mm |
Series |
ID-CX |
Display Type |
LCD character height 11 mm, Rotatable 330º |
Country of Origin |
JAPAN |
Type |
ABSOLUTE Flat Back |
Name of Manufacturer/Packer/Importer |
Mitutoyo |
Accuracy (Inch) |
0.0001 Inch |
Measuring Force |
1.8N or less |
Stem Diameter |
8 mm |
Hysteresis |
0.002 mm (0.0001 Inch) |
Scale |
Capacitance type, ABSOLUTE linear encoder |
Contact Point |
Carbide ball, thread : M 2.5x0.45 mm |
