| Model No | 543-782-10 |
| Type of Product | Digimatic Indicator |
| Measurement Range (mm) | 0-12.7 mm |
| Resolution (mm) | 0.01 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Model No |
543-782-10 |
Type of Product |
Digimatic Indicator |
Measurement Range (mm) |
0-12.7 mm |
Resolution (mm) |
0.01 mm |
Range (Inch) |
0-0.5 Inch |
Accuracy |
±0.02 mm |
Resolution |
0.0005 Inch |
Repeatability |
0.0005 Inch |
Repeatability (mm) |
0.01 mm |
Series |
ID-SX |
Country of Origin |
JAPAN |
Type |
Lug Back |
Name of Manufacturer/Packer/Importer |
Mitutoyo |
Accuracy (Inch) |
0.0008 Inch |
Measuring Force |
2.0N or less |
Stem Diameter |
8 mm |
Hysteresis |
0.02 mm (0.001 Inch) |
Scale |
Capacitance type, ABSOLUTE linear encoder |
Contact Point |
Carbide ball, thread : M 2.5x0.45 mm |
