| Type of Product | Clamp Meter |
| Voltage Accuracy (DC) | 1% ± 2 Digits |
| Weight | 180g |
| Dimension | 202 x 70 x 34mm |
Type of Product |
Clamp Meter |
Voltage Accuracy (DC) |
1% ± 2 Digits |
Weight |
180g |
Dimension |
202 x 70 x 34mm |
Battery Type |
1.5V AAA |
Display Type |
LCD |
Battery Life |
45 h |
Width |
70mm |
Height |
34mm |
Country of Origin |
Taiwan |
Safety Category |
CAT II 600 V, CAT III 300V |
Length |
202mm |
Safety Category Voltage |
300 V, 600V |
Maximum Operating Temperature |
+40°C |
Minimum Operating Temperature |
0°C |
AC Voltage Measurement Resolution |
100mV |
Resistance Measurement Accuracy |
1% ± 3 Digits |
Resistance Measurement Resolution |
1Ω |
Name of Manufacturer/Packer/Importer |
BK Precision |
Manufacturer Part Number |
BK316 |
Maximum AC Voltage Measurement |
600V ac |
Maximum AC Current Measurement |
100A ac |
Clamp Meter Type |
Mini AC/DC Clamp Meter |
Maximum DC Voltage Measurement |
600V dc |
Maximum DC Current Measurement |
100A dc |
AC Voltage Accuracy |
1.5% ± 5 Digits |
Calibrated |
UKAS |
Functions Measured |
AC Current, AC Voltage, DC Current, DC Voltage, Resistance |
Safety Category Levels |
CAT II, CAT III |
AC Current Accuracy |
3.5% ± 10 Digits |
Absolute Maximum Resistance Measurement |
10kΩ |
AC Current Measurement Resolution |
1mA |
DC Current Measurement Resolution |
1mA |
DC Current Accuracy |
4.5% ± 10 Digits |
Measurement Resolution |
100mV |
