| Type of Product | Clamp Meter |
| Weight | 340 g |
| Dimension | 78 x 42 x 222 mm |
| Battery Type | 9V 6LR61 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Clamp Meter |
Weight |
340 g |
Dimension |
78 x 42 x 222 mm |
Battery Type |
9V 6LR61 |
Power Source |
Battery |
Display Type |
LCD |
Battery Life |
130 h |
Width |
42 mm |
Height |
222 mm |
True Rms |
Yes |
Country of Origin |
China |
Safety Category |
CAT III 1000 V, CAT IV 600V |
Length |
78 mm |
Safety Category Voltage |
600V |
Maximum Operating Temperature |
+55°C |
Minimum Operating Temperature |
-20°C |
AC Voltage Measurement Resolution |
0.01V |
Resistance Measurement Resolution |
100mΩ |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Manufacturer Part Number |
P01120921 |
Clamp Meter Type |
AC Current Clamp Meter |
Calibrated |
UKAS |
Functions Measured |
AC Current, AC Voltage, DC Voltage, Resistance, Temperature |
Jaw Capacity Busbars |
34 mm |
Safety Category Levels |
CAT IV |
Absolute Maximum Resistance Measurement |
59.99Ω |
AC Current Measurement Resolution |
0.01A |
Temperature Measurement Resolution |
0.1°C |
Absolute Maximum Temperature Measurement |
+1000°C |
Absolute Maximum AC Voltage Measurement |
1400 V AC |
Absolute Maximum AC Current Measurement |
600 A AC |
Maximum Conductor Size |
34 mm |
Best AC Voltage Accuracy |
±1% + 3 Digits |
Best AC Current Accuracy |
±1% +3 digits |
Voltage Measurement Resolution |
0.01 V (DC) |
