| Type of Product | AC/DC Digital Clamp Meter |
| Frequency | 10 Hz to 10 MHz, AC Voltage: 10 Hz - 60 kHz |
| Weight | 230 g |
| Dimension | 215x63x63 mm |
Type of Product |
AC/DC Digital Clamp Meter |
Frequency |
10 Hz to 10 MHz, AC Voltage: 10 Hz - 60 kHz |
Weight |
230 g |
Dimension |
215x63x63 mm |
Model No |
9312-CB120 |
Capacitance |
60 nF/600 nF/6 µF/60 μF/600 µF |
Diode Test |
0-6 V |
Duty Cycle |
0.1% to 99.9% |
Temperature |
-40 to 1000°C |
Voltage (AC) |
6 V / 60 V / 600 V |
Voltage (Dc) |
600 mV / 6 V / 60 V / 600 V |
Resistance |
600 Ω/6 kΩ/60 kΩ/600 kΩ/2 ΜΩ/6 ΜΩ/60 ΜΩ |
DC Current |
60 A, 600 A |
AC Current (A) |
60 A, 600 A |
Power Supply |
2 x 1.5 V AAA Batteries |
Continuity Check |
< 30 Ω |
Package Contains |
1 x Main Unit, 2 x AAA Battery, 2 x Test Lead, 1 x K Type Thermocouple |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Insize |
