| Type of Product | Clamp Meter |
| Voltage Accuracy (DC) | ±(0.5% rdg + 2dgts) |
| Weight | 585 g |
| Dimension | 108 x 53 x 281 mm |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Clamp Meter |
Voltage Accuracy (DC) |
±(0.5% rdg + 2dgts) |
Weight |
585 g |
Dimension |
108 x 53 x 281 mm |
Model No |
MARCM87 |
Battery Type |
9 V |
Power Source |
Battery |
Display Type |
Bar Graphs, LCD |
Battery Life |
75 h |
Voltage Resolution (DC) |
1 mV |
Width |
53 mm |
Height |
281 mm |
Conductor Size |
57 mm |
True Rms |
Yes |
Country of Origin |
Taiwan, Province Of China |
Safety Category |
CAT II 1000 V; 10 A, CAT III 1000 V; 10 A, CAT IV 600V |
Length |
108 mm |
Safety Category Voltage |
1000 (CAT II & CAT III) V, 600 (CAT IV)V |
Maximum Operating Temperature |
+40 °C |
Minimum Operating Temperature |
0 °C |
AC Voltage Measurement Resolution |
1 mV |
Resistance Measurement Accuracy |
±1.0% + 5 digits |
Resistance Measurement Resolution |
100 mΩ |
Name of Manufacturer/Packer/Importer |
Martindale |
Manufacturer Part Number |
CM87 |
Maximum AC Voltage Measurement |
750 V AC |
Maximum AC Current Measurement |
1500 Amp AC |
Clamp Meter Type |
AC/DC Clamp Meter |
Maximum DC Voltage Measurement |
1000 V DC |
Maximum DC Current Measurement |
2000 A DC |
AC Voltage Accuracy |
±(1.5% rdg + 8dgts) |
Calibrated |
RSCAL |
Functions Measured |
AC Current, AC Voltage, Capacitance, DC Current, DC Voltage, Frequency, Resistance, Temperature |
Jaw Capacity Busbars |
57 mm |
Safety Category Levels |
CAT II, CAT III, CAT IV |
AC Current Accuracy |
±(2% rdg + 10dgts) |
Absolute Maximum Resistance Measurement |
66 MΩ |
AC Current Measurement Resolution |
100mA |
Temperature Measurement Resolution |
1 °C |
Absolute Maximum Temperature Measurement |
+1000 °C |
DC Current Measurement Resolution |
100 mA |
DC Current Accuracy |
±(2% rdg + 5dgts) |
Temperature Measurement Accuracy |
±1.0% + 2 digits |
