| Type of Product | Digital Clampmeter |
| Frequency | Upto 9.999 MHz |
| Dimension | 203 x 71 x 33 mm |
| Features | Backlight Display Orange Backlight for High Voltage Alert Torchlight for Clamp NCV (LED, Buzzer, EF Strength) |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Digital Clampmeter |
Frequency |
Upto 9.999 MHz |
Dimension |
203 x 71 x 33 mm |
Features |
Backlight Display Orange Backlight for High Voltage Alert Torchlight for Clamp NCV (LED, Buzzer, EF Strength) |
Model No |
3690P+ AUTO |
Audible Continuity |
50 Ω (approx.) |
Capacitance |
Upto 60 mF |
Diode Test |
1.0 ±0.6 mA (approx.) |
Duty Cycle |
0.1% - 99.9% |
Power Source |
Two 1.5 V Battery |
Voltage (AC) |
6 V, 60 V, 600 V (Auto) |
Voltage (Dc) |
6 V, 60 V, 600 V (Auto) |
Resistance |
Upto 60 MΩ |
DC Current |
60 A/ 600 A |
Display Type |
3⅚ Digits, 6000 Counts LCD Display |
Jaw Opening |
Cable Dia. 35 mm (max.) |
Battery Life |
200 Hours Typical |
AC Current (A) |
60 A / 600 A |
Function |
Autoranging, Audible Continuity, Diode Test, Data Hold |
Safety Standard |
CAT III 600V |
Package Contains |
Meter x 1 Pc Test Leads x 1 Pair 1.5V 'AAA' Battery x 2 Pcs Instruction Manual x 1 Pc Carrying Case x 1 Pc |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
MECO INSTRUMENTS |
Indicator Type |
Low Battery Indicator |
Measurement |
TRMS |
