| Type of Product | Digital AC Clamp Meter |
| Display | 3¾ Digits LCD Display |
| Display Counts | 4000 |
| Jaw Opening Size | 30 mm |
Type of Product |
Digital AC Clamp Meter |
Display |
3¾ Digits LCD Display |
Display Counts |
4000 |
Jaw Opening Size |
30 mm |
Voltage Range (DC) |
400 mV-600 V |
Voltage Accuracy (DC) |
±(2.0 % + 2 Digits) |
Current Range (AC) |
0-400 A |
Current Accuracy (AC) |
±(2.8 % + 8 Digits) |
Voltage Range (AC) |
0-600 V |
Voltage Accuracy (AC) |
±(2.5 % + 8 Digits) |
Resistance Accuracy |
±(3.5 % + 5 Digits) |
Capacitance Range |
40 nF-100 µF |
Capacitance Accuracy |
±(4.0 % + 10 Digits) |
Frequency |
10-10 kHz |
Frequency Accuracy |
±(1.5 % + 2 Digits) |
Temperature Range |
-20° to 760°C |
Temperature Accuracy |
±(3.0 % + 5°C) |
Power |
2 AAA Batteries 1.5 V |
Operating Environment |
5° to 40°C |
Storage Environment |
-20° to 60°C |
Relative Humidity |
< 80% RH |
Weight |
205 g |
Dimension |
200x66x37 mm |
Maximum Voltage Range (DC) |
0-600 V |
Max. AC Current Range |
0-400 A |
Maximum Voltage Range (AC) |
0-600 V |
Model No |
DT-225 |
Resistance Range (Ohm) |
0-40 MΩ |
