| Type of Product | MX 355 Clamp Meter |
| Weight | 243g |
| Dimension | 199 x 75 x 36mm |
| Model No | MX 355 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
MX 355 Clamp Meter |
Weight |
243g |
Dimension |
199 x 75 x 36mm |
Model No |
MX 355 |
Battery Type |
AAA |
Non-Contact Voltage Detector |
No |
Power Source |
Battery |
Display Type |
LCD |
Battery Life |
40 h |
Width |
75mm |
Height |
36mm |
True Rms |
Yes |
Country of Origin |
Taiwan, Province Of China |
Safety Category |
CAT III 600V |
Length |
199mm |
Safety Category Voltage |
600V |
Maximum Operating Temperature |
+40°C |
Minimum Operating Temperature |
0°C |
AC Voltage Measurement Resolution |
100mV |
Resistance Measurement Accuracy |
-11% + 2 Digits |
Resistance Measurement Resolution |
0.1 Ω |
Name of Manufacturer/Packer/Importer |
Metrix |
Pack of |
Each of 1 Piece |
Clamp Meter Type |
AC/DC Clamp Meter |
Functions Measured |
AC Current, AC Voltage, DC Current, DC Voltage, Frequency, Resistance |
Jaw Capacity Busbars |
30mm |
Safety Category Levels |
CAT III |
Absolute Maximum Resistance Measurement |
600 Ω |
AC Current Measurement Resolution |
10mA |
DC Current Measurement Resolution |
10mA |
Absolute Maximum DC Voltage Measurement |
600V dc |
Manufacturer Model Number |
MX0355Z |
Absolute Maximum AC Voltage Measurement |
600V ac |
Absolute Maximum AC Current Measurement |
400A ac |
Maximum Conductor Size |
30mm |
Best AC Voltage Accuracy |
-1(1.9% rdg + 5dgts) |
Best DC Voltage Accuracy |
-1(1% rdg + 3dgts) |
Best AC Current Accuracy |
-1(1,9% rdg + 5dgts) |
Voltage Measurement Resolution |
100mV |
Absolute Maximum DC Current Measurement |
400A dc |
Best DC Current Accuracy |
-1(2.5% rdg + 10dgts) |
