| Type of Product | Clamp Meter |
| Display | Maximum display 3200 counts, LCD display, with unit symbols |
| Model No | MR-117 |
| Voltage (AC) | 0 to 500 V (4 range auto) |
Type of Product |
Clamp Meter |
Display |
Maximum display 3200 counts, LCD display, with unit symbols |
Model No |
MR-117 |
Voltage (AC) |
0 to 500 V (4 range auto) |
Voltage (Dc) |
0 to 500 V (5 range auto) |
Accuracy |
AC current: ±2%rdg±8dgt AC voltage: ±2.3%rdg±6dgt DC voltage: ±1.3%rdg±3dgt Resistance: ±2%rdg±5dgt |
Resolution |
AC current: 0.01A AC voltage: 0.001V DC voltage: 0.1mV Resistance: 0.1Ω |
AC Current (A) |
30/300 (2 range auto) |
Power Supply |
LR44 (1.5V button battery) x 2 |
Resistance (Ω) |
300/3000 (2 range auto) |
Country of Origin |
CHINA |
Monotaro ID |
7135913 |
Included Components |
Test battery, instruction manual, test lead bar, soft case |
Name of Manufacturer/Packer/Importer |
MonotaRO |
Import Country |
Direct Import from Japan |
Clamp Diameter (Φmm) |
40 |
Acceptable Input |
AC current: 350A maximum (10 seconds) AC voltage/DC voltage: 600Vrms maximum Resistance: 250Vrms (10 seconds) |
