| Type of Product | AC Clamp Meter |
| Display | 3.5-digit LCD, Max. Reading of 3200 |
| Weight | Approx. 125 g |
| Model No | M-140 |
Type of Product |
AC Clamp Meter |
Display |
3.5-digit LCD, Max. Reading of 3200 |
Weight |
Approx. 125 g |
Model No |
M-140 |
Operating Temperature |
0℃ to 40℃, 80%RH max. (Without Condensation) |
Storage Temperature |
-10℃ to 60℃, 70%RH max. (Without condensation) |
Battery Life |
Approx. 50 hours (LR-44) |
Range |
AC 0～30 mA /300 mA, 30 A/300 A, 2 Range Manual |
Power Supply |
1.55V (SR-44, LR-44) x 2 |
Safety Standard |
IEC 61010-1, IEC 61010-2-032 Installation CategoryⅡ600V or CategoryⅢ300V. |
Size |
64(W)×162(H)×23(D) mm |
Power Consumption |
5 mW |
Standard |
EN 61326 |
Accessories |
Soft case:1, Instruction manual:1, Batteries LR-44(1.55V):2 |
Country of Origin |
India |
Over Range Indication |
“OL” mark on LCD |
Name of Manufacturer/Packer/Importer |
Taurus Powertronics Pvt. Ltd. |
Measuring Method |
Dual Slope Integration Mode |
Sampling Mode |
2 times/Sec (Digital Display), 12 Times/Sec (Bar Graph Display) |
