| Type of Product | Digital Clamp Multimeter |
| Power Source | Battery |
| Country of Origin | China |
| True Rms | Yes |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Digital Clamp Multimeter |
Power Source |
Battery |
Country of Origin |
China |
True Rms |
Yes |
Display Type |
Backlit LCD |
Width |
75 mm |
Height |
35 mm |
Weight |
295 g |
Length |
225 mm |
Battery Type |
AAA 1.5 V |
Dimension |
75 x 35 x 225 mm |
AC Voltage Measurement Resolution |
1mV |
Safety Category Voltage |
600V |
Maximum Operating Temperature |
40°C |
Minimum Operating Temperature |
5°C |
Safety Category |
CAT III 600V |
Temperature Measurement Accuracy |
1.5% + 5°C |
Resistance Measurement Accuracy |
1.2%L + 5 pts |
Manufacturer Part Number |
P06232009Z |
Resistance Measurement Resolution |
0.1Ω |
Name of Manufacturer/Packer/Importer |
RS Components & Controls (I) Ltd |
Absolute Maximum Temperature Measurement |
1000°C |
Functions Measured |
AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance, Temperature |
Safety Category Levels |
CAT III |
Absolute Maximum Resistance Measurement |
4000mΩ |
Temperature Measurement Resolution |
1°C |
AC Current Measurement Resolution |
10mA |
Absolute Maximum DC Voltage Measurement |
600 V DC |
Absolute Maximum AC Voltage Measurement |
600 V AC |
Best AC Voltage Accuracy |
±(1.2% + 5 pt) |
Best DC Voltage Accuracy |
±(0.5% + 8 pt) |
Best AC Current Accuracy |
±(2.5% + 10 pt) |
Absolute Maximum AC Current Measurement |
400 A AC |
AC Voltage Measurement Range |
600 V |
Non-Contact Voltage Detector |
Yes |
Maximum Conductor Size |
30 mm |
AC Current Measurement Range |
400 A |
Voltage Measurement Resolution |
0.1 mV (DC) |
Clamp Meter Type |
AC Current Clamp Meter |
