Ships within 19 days
View
View
View
View
| Type of Product | Digital Multimeter |
| Model No | KEWMATE2000A |
| Country of Origin | Japan |
| Continuous Operating Time (hrs) | Approximately 45 (auto power save approximately 10 minutes) |
Type of Product |
Digital Multimeter |
Model No |
KEWMATE2000A |
Country of Origin |
Japan |
Continuous Operating Time (hrs) |
Approximately 45 (auto power save approximately 10 minutes) |
Power Supply |
AAA battery R03 (1.5V) x 2 |
Resistance (Ω) |
340/3.4/34/340k/3.4/34M, ±1%rdg±3dgt(0 to 340kΩ), ±5%rdg±5dgt(3.4MΩ), ±15%rdg±5dgt(34MΩ) |
AC Current Range |
60.0A ±2%rdg±5dgt(50/60Hz) |
Resolution |
AC/DC 0.1A(min) |
DC current (A) |
60±2.0%rdg±5dgt |
AC Current (A) |
60±2%rdg±5dgt(50/60Hz) |
Applicable Standard |
IEC 61010-1 CAT III 300V/CAT II 600V Pollution Degree 2, IEC 61010-2-032, IEC 61326-1 |
Voltage (Dc) |
340 mV/3.4 V/34 V/340 V/600 V, (Input impedance: approx. 10MΩ), ±1.5%rdg±4dgt |
Continuity |
Buzzer sounds when 30 ± 10Ω or less |
AC Voltage (Volts) |
3.4/34/340/600 (input impedance: 10MΩ) ±1.5%rdg±5dgt (50 to 400Hz) |
Included Components |
AAA battery R03 (1.5V) x 2, instruction manual |
Monotaro ID |
84410095 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Kyoritsu Electrical Instruments Co., Ltd. |
Length (mm) |
27 |
Specifications |
Tip pin length: 18 mm |
Mass (g) |
Approx. 220 (including batteries) |
RoHS Directive |
Correspondence |
Suitable Battery |
AAA battery R03 (1.5V) x 2 |
Dimension (WxDxH) |
91x128x27 mm |
Dimensions, Length L x Width W x Depth D (mm) |
128x91x27 |
Frequency (kHz) |
(Current) 3.4/10±0.1%rdg±1dgt, (Voltage) 3.4/34/300±0.1%rdg±1dgt (Input sensitivity Current: 15A / Voltage: 30V or more) |
Conductor Diameter for Measurement |
Maximum Φ6 mm |
