| Type of Product | Insulation Resistance Meter |
| Model No | MG601-M |
| Voltage | 600V (AC/DC automatic discrimination) |
| Country of Origin | Japan |
Type of Product |
Insulation Resistance Meter |
Model No |
MG601-M |
Voltage |
600V (AC/DC automatic discrimination) |
Country of Origin |
Japan |
Power Supply |
LR03 (AAA alkaline battery, 1.5V) x 4 |
Display |
210 counts (MΩ), 9999 counts (V, Ω, continuity), 1999 counts (Hz) |
Frequency |
1999Hz |
Resistance |
0Ω to 999.9kΩ |
Measurement Range |
0.000M to 21.0MΩ [at 15V], 0.000M to 210MΩ |
Rated Voltage (V) |
15 / 500 |
Voltage (Dc) |
2000 mV |
Continuity |
Sounds at approximately 30 ohms or less |
Monotaro ID |
72187538 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Sanwa Electric Instrument Co., Ltd. |
Mass (g) |
298 |
RoHS Directive |
Correspondence |
Dimensions (H x W x D) (mm) |
147x68x33 |
