| Type | Digital Multimeters |
| Type of Product | Digital Multimeters |
| Model No | PC20 |
| Country of Origin | Japan |
Type |
Digital Multimeters |
Type of Product |
Digital Multimeters |
Model No |
PC20 |
Country of Origin |
Japan |
Power Supply |
R6P (AA) 1.5Vx2 |
Resistance (Ω) |
400/4k/40k/400k/4M/40M |
DC current (A) |
400μ/4000μ/40m/400m/4/10 |
AC Current (A) |
400μ/4000μ/40m/400m/4/10 |
Part No |
1-9716-01 |
Continuity Check |
Buzzer sound in the range of 10 to 120Ω or less Open voltage: Approximately 0.4V |
Diode Test |
Open circuit voltage: 0.4V |
Voltage (Dc) |
400m/4/40/400/1000 V |
AC Voltage (Volts) |
4/40/400/750 |
Fuse Type |
F1176 (0.5A / 250V Φ5 x 20mm ceramic tube) x 1, F1197 (12.5A / 250V Φ6.3 x 32mm glass tube) x 1 |
Included Components |
Test lead (TL-21a: total length about 1m / pin tip 18mm), holster (H-70), instruction manual |
Measurement Method |
Average method |
Monotaro ID |
34604552 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Sanwa Electric Instrument Co., Ltd. |
Height (mm) |
167 |
Length (mm) |
48 |
Width (mm) |
90 |
Mass (g) |
About 330 |
Maximum Count |
4000 |
RoHS Directive |
Correspondence |
Dimension (WxDxH) |
90x167x48 mm |
Trusco Part No. |
308-3667 |
Temperature/Humidity Range for Storage |
23 ± 5 ℃ 80% RH or less No condensation |
Operation Environment |
Humidity at 5-40 ° C is as follows, no condensation |
Capacitor Capacitance (μF) |
50 nF/500 nF/5 μF/50 μF/100μF |
