| Type of Product | Insulation Resistance Tester |
| Model No | MG102 |
| Country of Origin | Japan |
| Power Supply | LR6 (AA alkaline battery) x 4 |
Type of Product |
Insulation Resistance Tester |
Model No |
MG102 |
Country of Origin |
Japan |
Power Supply |
LR6 (AA alkaline battery) x 4 |
Display |
4000 counts (MΩ), 9999 counts (V Ω continuity) |
Frequency |
1999Hz |
Rated Voltage (V) |
50/100/125/250/500/1000 |
Voltage (Dc) |
600 V (AC / DC automatic discrimination) |
Continuity |
Sounds at approximately 30 ohms or less |
AC Voltage (Volts) |
600 (AC / DC automatic discrimination) |
Monotaro ID |
57277757 |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Sanwa Electric Instrument Co., Ltd. |
Specifications |
●MΩ (measurement range): 0.000M to 4000MΩ ●Ω: 999.9kΩ |
Mass (g) |
About 336 |
Wave Detection |
AC: True RMS method |
RoHS Directive |
Correspondence |
Rated Current (mA) |
1.0 to 1.2 |
Dimensions (H x W x D) (mm) |
147x68x33 |
