| Country of Origin | Japan |
| Power Supply | AC adapter or USB input (1m USB A-miniB cable included) |
| Type of Product | Temperature, Voltage, Humidity Data Logger |
| Part No | 3-6823-41 |
Country of Origin |
Japan |
Power Supply |
AC adapter or USB input (1m USB A-miniB cable included) |
Type of Product |
Temperature, Voltage, Humidity Data Logger |
Part No |
3-6823-41 |
Accuracy |
Voltage measurement accuracy: ±0.1% of FS, AC100V, humidity |
Model No |
ADL12T |
Function |
Functions: Real-time measurement on the application, start/stop recording, data saving, main unit settings, reading and displaying data from the SD card, display method: graph display (with overlapping display function), list display, maximum, minimum, average and comparison value display function for measurement data |
Included Components |
Simplified instruction manual, AC adapter, USB cable (approx. 1 m) (for power supply and co mmunication) |
Humidity Measurement Range (%) |
0 to 100 |
Monotaro ID |
13598055 |
Sampling Cycle |
5, 10, 30, 60sec, 5, 10, 30, 60min |
Mass (g) |
About 250 |
Measurement accuracy |
±5%RH(TYP)(10 to 95%RH at23℃) |
Name of Manufacturer/Packer/Importer |
AS ONE Corporation |
Import Country |
Direct Import from Japan |
Dimension (mm) |
167x91x35.8 |
Temperature Measurement Accuracy |
±0.05% of rdg +1.0℃(K：-100 to +1370℃ at25℃), |
Specifications |
●Main unit, Thermocouple measurement: B, R, S, N, K, E, J, T (select one), DC voltage measurement: 100, 500mV, 1, 5, 10, 50V, DC, Input channel: Analog/12CH, Humidity measurement +5V-OUT/1CH, PC I/F: USB2.0 (full speed) Mini B type, Card slot: 1 port, SDHC compatible, Usable memory: 64GB to 32GB (SDXC not supported), Memory: SD card, PC save using application, Recording format: CSV, saved to 1 file from start of recording, Number of recordings: 5,000,000 times (for 2GB) ●Differences from previous model number: Rear terminal block (check 3-6823-31 ADL 12N for changes) |
Measurement Temperature Range (℃) |
-200 to +1370 (when using K thermocouple) |
Supported OS |
Windows(R)8/8.1/10(32, 64bit) |
Input terminals |
Screw terminal M3/*M3.5 (external dimension 6.2 mm or less/internal diameter 3.2 mm or more), |
Ac Power |
Input: AC 100-240 V, 50/60 Hz, 2 Amp, Output: DC 5 V, 1 Amp |
