| Type of Product | Automatic Flash Timer |
| Model No | EEU-TP1H |
| Type | Automatic flashing add-on |
| Monotaro ID | 52749987 |
Type of Product |
Automatic Flash Timer |
Model No |
EEU-TP1H |
Type |
Automatic flashing add-on |
Monotaro ID |
52749987 |
Type of Sign |
Conventional mounting, surface screw mounting, and DIN rail mounting |
Tip Shape |
Circuit configuration: EE + timer |
Country of Origin |
Japan |
Minimum setting unit |
1 minute min-1[rpm] |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Kawamura Electric Industry Co., Ltd. |
Circuits |
Output: 1 |
Timer |
24-hour timer |
Specifications |
●Program cycle: 24 hours ●ON-OFF frequency: 1 time/day ●Clock accuracy: ±15 seconds per month (25°C) |
Operating Temperature / Humidity Range |
-10 to 50°C, 85% or less |
Power Outage Compensation Time |
Decade |
Applicable Load |
Incandescent bulb: 600W, fluorescent lamp (glow): 500W, fluorescent lamp (inverter): 400W |
Operating voltage (V) |
AC100 50/60 Hz |
Output Format |
No-voltage a contact |
Outer Dimensions (mm) |
99.6x74.5x78 |
Mass (Kg) |
0.195 |
Method |
Crystal oscillation type |
Display Format |
24-hour display |
Contact Capacity |
AC 100 V 15A (power factor = 1) |
