| Type of Product | Automatic Flash Timer |
| Model No | EEU-EPH |
| Type | Automatic flashing add-on |
| Monotaro ID | 52749978 |
Type of Product |
Automatic Flash Timer |
Model No |
EEU-EPH |
Type |
Automatic flashing add-on |
Monotaro ID |
52749978 |
Type of Sign |
Conventional mounting, surface screw mounting, and DIN rail mounting |
Tip Shape |
Circuit configuration: 3 circuits identical |
Country of Origin |
Japan |
Import Country |
Direct Import from Japan |
Name of Manufacturer/Packer/Importer |
Kawamura Electric Industry Co., Ltd. |
Circuits |
Output: 3 |
Operating Temperature / Humidity Range |
-10 to 50°C, 85% or less |
Applicable Load |
Incandescent bulb: 600W, fluorescent lamp (glow): 500W, fluorescent lamp (inverter): 400W |
Operating voltage (V) |
AC100 50/60 Hz |
Output Format |
No-voltage a contact |
Outer Dimensions (mm) |
99.6x74.5x78 |
Mass (Kg) |
0.19 |
Output Current |
Total 3A (power factor = 1) |
Output Voltage |
Same as operating voltage |
Contact Capacity |
Each AC 100 V 15A (power factor = 1) |
