| Type of Product | Dip Timer |
| Model No | H3FA-SBU-DC12/24 |
| Storage Temperature | -25 to +65 ℃ (no icing) |
| Control Output | Contactless, DC30V 150mA max., Residual voltage when ON: 1.0V or less |
Type of Product |
Dip Timer |
Model No |
H3FA-SBU-DC12/24 |
Storage Temperature |
-25 to +65 ℃ (no icing) |
Control Output |
Contactless, DC30V 150mA max., Residual voltage when ON: 1.0V or less |
Shock Resistance |
1000 m/s² 6 directions 3 times each |
Rated Voltage (V) |
DC 12/24 |
Monotaro ID |
46628504 |
Mass (g) |
About 10 |
Influence of Voltage |
± 1% or less (percentage of the maximum scale time, but ± 5% or less for DC5, 6, 5 / 6V |
Return Function |
External reset |
Withstand Voltage |
Between control output and operation circuit: AC 1500 V 50/60 Hz 1 min, Between non-continuous contacts: AC 1000 V 50/60 Hz 1 min |
Ambient Humidity to Use |
35 to 85% |
Type of Sign |
Surface mounting (IC socket or printed circuit board directly attached) |
Timed Contacts |
Non-contact output |
Power Consumption (mW) |
About 100 / about 240 |
Adjustable Time |
6s to 60min (4 specification multi: 0.6 to 6s, 6 to 60s, 0.6 to 6min, 6 to 60min) |
Operation Type |
Instantaneous operation, timed recovery |
Power Supply Voltage |
Ripple 20% or less |
Country of Origin |
JAPAN |
Import Country |
Direct Import from Japan |
Vibration Resistance (Destruction) |
10 to 55 Hz, 0.375 mm single amplitude, 3 directions, 1h each |
Influence of Temperature |
± 5% or less (ratio to the maximum scale time) (In the case of time specification 1 second, each standard value ± 10 ms) |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Insulation Resistance (MOhm) |
100 mΩ Or More (With DC 500 V Mega) |
Operation Ambient Temperature (°C) |
-10 to +55 (no freezing) |
