| IP Camera Input | Up to 5 Channels of IPC Access 1 IP Channel by Default + 4 Channels (Analog Channels are Converted to IP Channels) | Incoming Bandwidth: 20 Mbps, Recording Bandwidth: 20 Mbps and Outgoing Bandwidth: 20 Mbps (After IP extension is enabled, the AI Function (SMD) will be disabled) |
| Analog Camera Input | 4 BNC Ports, Supports HDCVI/AHD/TVI/CVBS Autodetect |
| Video Output | 1 HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720; 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
| Power Supply | 12 VDC, 1.5 A |
IP Camera Input |
Up to 5 Channels of IPC Access 1 IP Channel by Default + 4 Channels (Analog Channels are Converted to IP Channels) | Incoming Bandwidth: 20 Mbps, Recording Bandwidth: 20 Mbps and Outgoing Bandwidth: 20 Mbps (After IP extension is enabled, the AI Function (SMD) will be disabled) |
Analog Camera Input |
4 BNC Ports, Supports HDCVI/AHD/TVI/CVBS Autodetect |
Video Output |
1 HDMI: 1920 × 1080, 1280 × 1024, 1280 × 720; 1 VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 |
Power Supply |
12 VDC, 1.5 A |
Operating Temperature |
-10°C to +45°C (+14°F to +113°F) |
Type of Product |
Digital Video Recorder |
Weight |
540 g |
User Interface |
Web, Local GUI |
Resolution |
1080p |
Operating System |
Embedded Linux |
Camera Inputs |
(1) CVI: 1080p@25/30 fps, 720p@50/60 fps, 720p@25/30 fps (2) TVI: 1080p@25/30 fps, 720p@25/30 fps (3) AHD: 1080p@25/30 fps, 720p@25/30 fps |
Processor |
Industrial-Grade Processor |
Power Consumption |
<7 W (without HDD) |
No. of Channels |
4 Channels |
Color |
Black |
Dimension |
197x204x41.5 mm |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Aditya Infotech Limited |
Operating Humidity |
10%–90% (RH), non-condensing |
Storage Temperature |
-20°C to +60°C (–4°F to +140°F) |
Streaming Capability |
Dual Stream |
