| Type of Product | Dip Switch |
| Model No | A6T-7101 |
| Country of Origin | CHINA |
| Name of Manufacturer/Packer/Importer | Omron Corporation |
Type of Product |
Dip Switch |
Model No |
A6T-7101 |
Country of Origin |
CHINA |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Monotaro ID |
46479072 |
Operating Temperature Range |
-20 to +70 60% RH or less ℃ (with no icing or condensation) |
Import Country |
Direct Import from Japan |
Type |
Flat type (standard) |
Part No |
64-3337-34 |
Contact Resistance (ohm) |
200 mΩ or Less (initial value) |
Insulation Resistance (MOhm) |
100 or more (at 250 V DC) |
Withstand Voltage |
Between terminals: AC 500 V 1 min |
Electrical ratings |
24 V DC 25 mA, 3.5 V DC 10 μA (minimum current) |
Operating Humidity Range |
35 to 95% RH (at +5 to + 35°C) |
Dimension A (Φmm) |
18.72 |
Operating Force (N) |
0.29 to 9.8 |
Electrical Durability |
1000 times or more |
Vibration Resistance (Malfunction) |
10-55 Hz double amplitude 1.5 mm |
No. of Pole |
7 |
Shock Resistance (Malfunction) |
300 m/s² or more |
