Ships within 19 days
Model No
No. of Pole
View
View
View
View
| Type of Product | Sealed Dip Switch |
| Model No | A6D-9103 |
| Color | (Strike lever) Orange |
| Series | A6D Series |
Type of Product |
Sealed Dip Switch |
Model No |
A6D-9103 |
Color |
(Strike lever) Orange |
Series |
A6D Series |
Pack of |
1 Pcs |
Country of Origin |
Japan |
Name of Manufacturer/Packer/Importer |
Omron Corporation |
Monotaro ID |
46445953 |
Operating Temperature Range |
-20 to +70℃ 60% RH or less (with no icing or condensation) |
Import Country |
Direct Import from Japan |
Type |
Convex Type |
Part No |
64-3335-60 |
Contact Resistance (ohm) |
100 or less (initial value) |
Insulation Resistance (MOhm) |
100 mohm or more (at 250 VDC) |
Withstand Voltage |
Between terminals: AC500V 1min |
Electrical ratings |
30V DC 30mA, 3.5V DC 10μA (minimum current) |
Operating Humidity Range |
35 to 95% RH (at +5 to + 35 ° C) |
Dimension A (Φmm) |
24.9±0.2 |
Operating Force (N) |
0.29 to 4.9 |
Electrical Durability |
2000 times or more |
Vibration Resistance (Malfunction) |
10-55Hz double amplitude 1.5 mm |
No. of Pole |
9 |
Shock Resistance (Malfunction) |
300 m/s² or more |
