| Type | Exposure Type |
| Model No | S16-514C |
| Protection Class | IP2XD |
| Type of Product | S-Type Panel Cabinet |
Type |
Exposure Type |
Model No |
S16-514C |
Protection Class |
IP2XD |
Type of Product |
S-Type Panel Cabinet |
Country of Origin |
Japan |
Material |
Iron |
Name of Manufacturer/Packer/Importer |
Nitto Kogyo Co., Ltd. |
Monotaro ID |
35296247 |
Import Country |
Direct Import from Japan |
Paint Color |
Cream (Munsell Value, 2.5Y9 / 1) |
Mass (Kg) |
44 |
Handle |
Plane handle |
Wall Thickness (mm) |
(Door) 1.6 / (Body) 1.6 / (Front frame) 2.3 |
Material (Circuit Board) |
Made of Iron |
RoHS Directive |
Correspondence |
Circuit Board Dimensions, Length x Width (mm) |
1320x420 |
Effective Depth (mm) |
135 |
Dimensions, Length L x Width W x Depth D (mm) |
1400x500x160 |
Door Dimensions, Height x Width (mm) |
1354x454 |
Substrate Thickness |
2.3 mm |
Door Opening / Closing Pattern |
One-SIded |
