Ships within 25 days
View
View
View
View
| Model No | B12-66LC |
| Protection Class | IP2XC |
| Type of Product | BL Thermal Equipment Storage Cabinet |
| Country of Origin | Japan |
Model No |
B12-66LC |
Protection Class |
IP2XC |
Type of Product |
BL Thermal Equipment Storage Cabinet |
Country of Origin |
Japan |
Material |
Iron |
Door Type |
One door |
Name of Manufacturer/Packer/Importer |
Nitto Kogyo Co., Ltd. |
Monotaro ID |
44645867 |
Import Country |
Direct Import from Japan |
Paint Color |
Cream Painting (2.5Y9 / 1) |
Mass (Kg) |
18.2 |
Handle |
Flat handle small (H-11AN) |
Material (Circuit Board) |
Wooden 15 mm |
Dimension L (mm) |
554 |
RoHS Directive |
Correspondence |
Effective Depth (mm) |
101 |
Thickness (mm) |
Door: 1.6 Body: 1.6 Front frame: 1.6 |
Installation Location |
For indoor use |
Board Dimensions (width W x height H) (mm) |
520x520 |
Dimension I (mm) |
480 |
Dimension H (Φmm) |
480 |
Dimension O |
477.4 mm |
Dimension P |
57.4 mm |
Shape Drawing Number |
C |
Dimension K |
554 mm |
Dimension Q (mm) |
23.8 |
