| Type | Exposure Type |
| Model No | S20-78-2 |
| Protection Class | IP2XC |
| Type of Product | S-Type Panel Cabinet with Double Doors |
Type |
Exposure Type |
Model No |
S20-78-2 |
Protection Class |
IP2XC |
Type of Product |
S-Type Panel Cabinet with Double Doors |
Country of Origin |
Japan |
Material |
Iron |
Name of Manufacturer/Packer/Importer |
Nitto Kogyo Co., Ltd. |
Monotaro ID |
35300553 |
Import Country |
Direct Import from Japan |
Paint Color |
Light Beige (Munsell Value, 5Y7 / 1) |
Mass (Kg) |
35.799999999999997 |
Handle |
Plane handle |
Wall Thickness (mm) |
(Door) 1.6 / (body) 1.6 / (front frame) 1.6 |
Material (Circuit Board) |
Made of Iron |
RoHS Directive |
Correspondence |
Circuit Board Dimensions, Length x Width (mm) |
720x620 |
Effective Depth (mm) |
181 (Matching part / 145) |
Dimensions, Length L x Width W x Depth D (mm) |
800x700x200 |
Door Dimensions, Height x Width (mm) |
754x326 |
Substrate Thickness |
2.3 mm |
Door Opening / Closing Pattern |
Double Open |
