| Model No | CX-F121-Z-W |
| Protection Class | IP67(IEC) |
| Type of Product | Compact Laser Distance Sensor |
| Voltage | 12 to 24 DC ±10%, ripple P-P 10% or less |
Model No |
CX-F121-Z-W |
Protection Class |
IP67(IEC) |
Type of Product |
Compact Laser Distance Sensor |
Voltage |
12 to 24 DC ±10%, ripple P-P 10% or less |
Country of Origin |
Japan |
Specifications |
●Short distance protection: Equipped (automatic recovery type) ●Black and white error: Within 5% of the set distance |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Monotaro ID |
58761678 |
Import Country |
Direct Import from Japan |
Applicable Standard |
CE marking (EMC directive, RoHS directive) |
RoHS Directive |
Correspondence |
Emitting Element |
Class 1 laser (Note 4) Peak emission wavelength: 940 nm (invisible infrared) |
Beam Diameter |
Typical examples: approx. 32 (distance 1,000 mm), approx. 105 (distance 3,000 mm) |
Response |
Within 15% of the detection distance (detection distance less than 900)<br> Within 8% of the detection distance (detection distance 900 or more) |
Detection Distance (mm) |
50 to 3000 Values for white non-glossy paper (200x200). |
Current Consumption (mA) |
40 or less |
Setting Range |
100 to 3000 mm Values are for white non-glossy paper (200x200 mm). |
Output Operation |
ON when light is received / ON when no light is received (switchable) |
