| Model No | BHM35342LJ2 |
| Color | White (Munsell symbol 10Y9/0.5) |
| Type of Product | Residential Distribution Board |
| Country of Origin | Japan |
Model No |
BHM35342LJ2 |
Color |
White (Munsell symbol 10Y9/0.5) |
Type of Product |
Residential Distribution Board |
Country of Origin |
Japan |
Material |
Plastic |
Specifications |
(Number Of Branch Current Sensors) 39, With Retraction Method (Limiter Space) |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Function |
Residential distribution board compatible with creation-storage cooperation system For independent output (single-phase 2-wire) |
Monotaro ID |
51388577 |
Import Country |
Direct Import from Japan |
No. of Circuits |
Implementation: 34 |
Circuit space |
2 |
Main capacity (A) |
50 |
No. of Terminals |
11 |
Contents |
(2P1E 20 Amp)27, (2P2E 20 Amp 100 V)6, (2P2E 30 Amp 200 V)1 |
Structure |
With Door, Both Exposed And Semi-Recessed Type |
Applicable Standard |
(Certified) Japan Wiring System Industry Association Residential Distribution Board Standard Compliant Product |
