| Type | Advanced |
| Model No | BQE85263GJD |
| Color | White (Munsell symbol 10Y9/0.5) |
| Type of Product | Cosmo Panel |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type |
Advanced |
Model No |
BQE85263GJD |
Color |
White (Munsell symbol 10Y9/0.5) |
Type of Product |
Cosmo Panel |
Country of Origin |
Japan |
Material |
Plastic |
Specifications |
No retraction method (limiter space) |
Width (mm) |
722 |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Function |
Compatible with 3 battery interconnection |
Monotaro ID |
51395507 |
Import Country |
Direct Import from Japan |
No. of Circuits |
(Implementation) 26 |
Circuit space |
3 |
Main capacity (A) |
50 |
No. of Terminals |
12 |
Depth (mm) |
111 |
Breaker capacity |
30 Amp |
Contents |
(2P1E 20 Amp)20, (2P2E 20 Amp)6 |
Height (mm) |
325 |
Chip Breaker |
Compact interconnection for fuel cells: 20A, compact interconnection for storage batteries: 20A |
Semi-embedded dimensions (length x width x depth) (mm) |
310x707x30 |
Structure |
With Door, Both Exposed And Semi-Recessed Type |
Applicable Standard |
(Certified) Japan Wiring System Industry Association Residential Distribution Board Standard Compliant Product |
