| Type | Residential Distribution Board |
| Model No | BDJ7263C2E4 |
| Series | FLEXIID |
| Color | White (Munsell symbol N9.3) |
Type |
Residential Distribution Board |
Model No |
BDJ7263C2E4 |
Series |
FLEXIID |
Color |
White (Munsell symbol N9.3) |
Door |
Attached |
Type of Product |
Residential Distribution Panel |
Standard |
HP mark: Japan Wiring Systems Industry Association residential distribution board standard compliant product |
Country of Origin |
Japan |
Material |
Plastic |
Specifications |
ELB 2P2E 40 Amp 15 mA 200 V：1 |
Width (mm) |
550 |
Name of Manufacturer/Packer/Importer |
Panasonic Corporation |
Function |
EV/PHEV charging circuit (40A), solar power generation system (30A), EcoCute, IH compatible |
Monotaro ID |
15653228 |
Mounting |
Exposure type |
Import Country |
Direct Import from Japan |
Space |
None |
Main capacity (A) |
75 |
No. of Terminals |
18 |
Depth (mm) |
100 |
Breaker capacity |
30 Amp |
Contents |
(2P1E 20 Amp) 18, (2P2E 20 Amp 100 V) 6, (2P2E20A200V)1, (2P2E 30 Amp 200 V) 1 |
Height (mm) |
350 |
Quantity |
One |
Chip Breaker |
EV/PHEV charging circuit compatible: 40A |
