| Type of Product | Dome Camera |
| Power Consumption | Max 9.37 W (12 VDC, IR on) |
| Minimum Illumination | 0.01 lux@F2.0 (Color, 30 IRE), 0.001 lux@F2.0 (B/W, 30 IRE), 0 lux (IR on) |
| Power Supply | 12 VDC |
Type of Product |
Dome Camera |
Power Consumption |
Max 9.37 W (12 VDC, IR on) |
Minimum Illumination |
0.01 lux@F2.0 (Color, 30 IRE), 0.001 lux@F2.0 (B/W, 30 IRE), 0 lux (IR on) |
Power Supply |
12 VDC |
Image Sensor |
1/3" 2.4MP PS CMOS Image Sensor |
Resolution |
2.4 MP (1920 × 1080), 960H (960 × 576/ 960 × 480) |
Model No |
CP-UMC-DA24L4-L |
Lens |
3.6mm Lens |
Lens Type |
Fixed-focal |
Viewing Angle |
Pan: 0°–360°, Tilt: 0°–78°, Rotation: 0°–360° |
Operating Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
Noise Reduction |
2D NR |
Dimension |
109.9 mm × 105.9 mm |
S/N Ratio |
>55dB |
Aperture |
F2.0 Max. |
Shutter Speed |
PAL: 1/25 s–1/100000 s, NTSC: 1/30 s–1/100000 s |
Audio |
Built-in Mic, up to 8 m |
Frame Rate |
CVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps; AHD: PAL: 1080p@25 fps; NTSC: 1080p@30 fps; TVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps; CVBS: PAL: 960H; NTSC: 960H |
Lens Mount |
M12 |
IR Range |
40 m |
Storage Temperature |
–40 °C to +60 °C (–40 °F to +140 °F) |
Operating Humidity |
<95% (RH), non-condensing |
Country of Origin |
India |
Name of Manufacturer/Packer/Importer |
Adtiya Infotech Ltd |
Storage Humidity |
<95% (RH), non-condensing |
IR Control Type |
Auto, Manual |
Camera Audio Support |
CVI, TVI |
Casing Material |
Dome (metal + plastic) + plastic enclosure |
