| Type of Product | General-Purpose Earth Leakage Breaker |
| No. of Pole | 3 Pole |
| Model No | EW250RAGU-3P200B |
| Rated Breaking Capacity (kA) | IEC60947-2/JIS C 8201-2-2/EN60947-2：(AC 440/415/400/380 V)50/25-(AC 230/200 V)100/50-(AC 100 V)100/50, GB/T14048.2：(AC 400 V)50/25-(AC 230 V)100/50, UL489 CAN/CSA C22.2 NO.5：(AC 480 V/△)50-(AC 480 V/Y)50-(AC 240 V)100 |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
General-Purpose Earth Leakage Breaker |
No. of Pole |
3 Pole |
Model No |
EW250RAGU-3P200B |
Rated Breaking Capacity (kA) |
IEC60947-2/JIS C 8201-2-2/EN60947-2：(AC 440/415/400/380 V)50/25-(AC 230/200 V)100/50-(AC 100 V)100/50, GB/T14048.2：(AC 400 V)50/25-(AC 230 V)100/50, UL489 CAN/CSA C22.2 NO.5：(AC 480 V/△)50-(AC 480 V/Y)50-(AC 240 V)100 |
Frame (AF) |
250 |
Rated Sensitivity Current (mA) |
50/100/200/500 switch |
Monotaro ID |
50185222 |
Rated Current (A) |
200 |
Country of Origin |
Japan |
Connection Type |
Surface type (hexagon socket head cap screw) |
Rated operating voltage (AC V) |
IEC: 100-230-440 shared / UL: 240-480 shared |
Series |
G-TWIN |
No. of Elements |
3E |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Import Country |
Direct Import from Japan |
