| Type of Product | General-Purpose Auto-Breaker |
| No. of Pole | 2 Pole |
| Model No | BW250EAGU-2P225 |
| Rated Breaking Capacity (kA) | IEC60947-2/JIS C 8201-2-1/EN60947-2：(AC 500V)10/5-(AC 440/415/400/380V)18/9-(AC 240/230V)36/18-(DC 250V)10/5, GB/T14048.2：(AC 400V)18/9-(AC 230V)36/18, UL489 CAN/CSA C22.2 NO.5：(AC 240V)22-(DC 125/250V)10 |
Type of Product |
General-Purpose Auto-Breaker |
No. of Pole |
2 Pole |
Model No |
BW250EAGU-2P225 |
Rated Breaking Capacity (kA) |
IEC60947-2/JIS C 8201-2-1/EN60947-2：(AC 500V)10/5-(AC 440/415/400/380V)18/9-(AC 240/230V)36/18-(DC 250V)10/5, GB/T14048.2：(AC 400V)18/9-(AC 230V)36/18, UL489 CAN/CSA C22.2 NO.5：(AC 240V)22-(DC 125/250V)10 |
Frame (AF) |
250 |
Monotaro ID |
50078174 |
Rated Current (A) |
225 |
Country of Origin |
Japan |
Rated Insulation Voltage (V) |
AC 690/DC 250 |
Connection Type |
Surface type (screw terminal) |
No. of Elements |
2E |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Import Country |
Direct Import from Japan |
