| Type of Product | Earth Leakage Breaker |
| No. of Pole | 3 Pole |
| Model No | EW100EAN-3P100B4B |
| Operating Time | (High speed type) 0.1s (maximum) |
Warranty as per brand
100% Original Products
Secure payments
100% Buyer protection
Top Brands
Type of Product |
Earth Leakage Breaker |
No. of Pole |
3 Pole |
Model No |
EW100EAN-3P100B4B |
Operating Time |
(High speed type) 0.1s (maximum) |
Phase / Wire Type |
1Φ3W |
Rated Breaking Capacity (kA) |
JIS C 8201-2-2 Ann.2：(AC 100/200V)25 |
Overcurrent Tripper Type |
Complete electromagnetic type |
Rated Sensitivity Current (mA) |
30 |
Monotaro ID |
64022273 |
Rated Current (A) |
100 |
Country of Origin |
Japan |
Connection Type |
Surface type (screw terminal) |
Trip button |
Included |
Reverse Connection |
Impossible |
No. of Elements |
2E |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Import Country |
Direct Import from Japan |
Selector Switch Type |
None |
Rated Operating Voltage (V) |
AC 100/200 |
Rated Impulse Withstand Voltage (kV) |
4 |
Rated Operating Overvoltage |
135 V |
Display Method |
Mechanical button |
Rated Non-Operational Overvoltage (V) |
120 |
Pollution Degree (Environment to Use) |
2 |
