| Type of Product | Earth Leakage Breaker |
| No. of Pole | 3 Pole |
| Model No | EW400HAGU-3P250B |
| Rated Breaking Capacity (kA) | IEC60947-2 / JIS C 8201-2-2 / EN60947-2: (AC440 / 415/400 / 380 V) 70/35, (AC230 / 200 V) 125/63, (AC100 V) 125/63, GB / T14048.2 : (AC400 V) 70/35/ (AC230 V) 125/63, UL489 CAN / CSA C22.2 NO.5: (AC480V / △) 65 (with block terminal: 50)/ (AC480V / Y) 65 (with block terminal) : 50) / (AC240 V) 100 |
Type of Product |
Earth Leakage Breaker |
No. of Pole |
3 Pole |
Model No |
EW400HAGU-3P250B |
Rated Breaking Capacity (kA) |
IEC60947-2 / JIS C 8201-2-2 / EN60947-2: (AC440 / 415/400 / 380 V) 70/35, (AC230 / 200 V) 125/63, (AC100 V) 125/63, GB / T14048.2 : (AC400 V) 70/35/ (AC230 V) 125/63, UL489 CAN / CSA C22.2 NO.5: (AC480V / △) 65 (with block terminal: 50)/ (AC480V / Y) 65 (with block terminal) : 50) / (AC240 V) 100 |
Frame (AF) |
400 |
Rated Sensitivity Current (mA) |
30 |
Monotaro ID |
50188266 |
Rated Current (A) |
250 |
Country of Origin |
Japan |
Connection Type |
Surface type (flat terminal) |
Rated operating voltage (AC V) |
IEC: 100-230-440 shared / UL: 240-480 shared |
No. of Elements |
3E |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Import Country |
Direct Import from Japan |
