| Type of Product | General-Purpose Wiring Auto-Breaker |
| No. of Pole | 2 Pole |
| Model No | BW400HAGU-2P250 |
| Overcurrent Tripper Type | Thermal-electromagnetic |
Type of Product |
General-Purpose Wiring Auto-Breaker |
No. of Pole |
2 Pole |
Model No |
BW400HAGU-2P250 |
Overcurrent Tripper Type |
Thermal-electromagnetic |
Monotaro ID |
50082094 |
Rated Current (A) |
250 |
Breaking Capacity |
High-performance type |
Country of Origin |
Japan |
Application |
AC/DC shared |
Terminal Screw |
Hexagon bolt M12x35, 4 pieces |
Rated Insulation Voltage (V) |
AC 690/DC 250 |
Trip button |
Included |
Reverse Connection |
Possible |
No. of Elements |
2E |
Name of Manufacturer/Packer/Importer |
Fuji Electric Co., Ltd. |
Import Country |
Direct Import from Japan |
Rated Impulse Withstand Voltage (kV) |
6 |
Pollution Degree (Environment to Use) |
3 |
Rated Frequency (Hz) |
50-60 |
Dimension B (Φmm) |
257 |
Isolation |
Conformity |
Dimension A (Φmm) |
140 |
Dimension d |
146 mm |
Dimension C |
103 mm |
