| Type of Product | No-Fuse Breaker |
| Model No | NL63E-10 |
| Rated Breaking Capacity (kA) | 2.5(AC 200 V) |
| Frame (AF) | 60 |
Type of Product |
No-Fuse Breaker |
Model No |
NL63E-10 |
Rated Breaking Capacity (kA) |
2.5(AC 200 V) |
Frame (AF) |
60 |
Mass (Kg) |
0.42 |
Rated Voltage (V) |
AC200 |
Monotaro ID |
52735743 |
Rated Current (A) |
10 |
Country of Origin |
Japan |
Application |
JIS agreement module |
Connection Type |
Wire clamp terminal (M5) |
Reverse Connection |
Impossible |
Included Components |
Terminal cover (Built-in sealing plate) 2 pieces / Mounting screw (for both iron plate and wood board) 2 pieces / DIN hook 1 piece |
Name of Manufacturer/Packer/Importer |
Kawamura Electric Industry Co., Ltd. |
Import Country |
Direct Import from Japan |
No. of Poles / Elements |
3P3E |
Connectable Wire (mm2) |
22 |
Outer Dimensions (mm) |
75x100x60 |
Tripper Type |
Complete electromagnetic type |
