| Type of Product | Earth Leakage Breaker |
| Model No | ZL63-15-15 |
| Dimension | 75x100x60 mm |
| Operating Time | Within 0.1 seconds |
Type of Product |
Earth Leakage Breaker |
Model No |
ZL63-15-15 |
Dimension |
75x100x60 mm |
Operating Time |
Within 0.1 seconds |
Phase / Wire Type |
3Φ3W |
Rated Breaking Capacity (kA) |
2.5(AC 100 V)/2.5(AC 200 V) |
Frame (AF) |
60 |
Mass (Kg) |
0.45 |
Rated Voltage (V) |
AC100-200 |
Rated Sensitivity Current (mA) |
15 |
Monotaro ID |
52735165 |
Rated Current (A) |
15 |
Country of Origin |
Japan |
Application |
Master / general / JIS agreement |
Connection Type |
Wire clamp terminal (M5) |
Reverse Connection |
Impossible |
Included Components |
Terminal cover (Built-in sealing plate) 2 pieces / Mounting screw (for both iron plate and wood board) 2 pieces / DIN hook 1 piece |
Name of Manufacturer/Packer/Importer |
Kawamura Electric Industry Co., Ltd. |
Import Country |
Direct Import from Japan |
No. of Poles / Elements |
3P3E |
Connectable Wire (mm2) |
22 |
Outer Dimensions (mm) |
75x100x60 |
Tripper Type |
Complete electromagnetic type |
Outer Dimensions |
75x100x60 mm |
Safety Standard |
Electrical Appliance and Material Safety Law |
