| Type of Product | No-Fuse Breaker |
| Model No | NB103-60TLA |
| Rated Breaking Capacity (kA) | 10(AC 100/200 V) |
| Frame (AF) | 100 |
Type of Product |
No-Fuse Breaker |
Model No |
NB103-60TLA |
Rated Breaking Capacity (kA) |
10(AC 100/200 V) |
Frame (AF) |
100 |
Mass (Kg) |
0.8 |
Rated Voltage (V) |
AC100/200 |
Monotaro ID |
52736443 |
Rated Current (A) |
60 |
Country of Origin |
Japan |
Application |
For distribution board master / AA only |
Connection Type |
Crimp terminal (M8) |
Reverse Connection |
Impossible |
Included Components |
Terminal cover 2 pieces / Mounting screw (for iron plate) 2 pieces / Mounting screw (for wood board) 2 pieces / Seal pin 2 pieces / Crimping terminal 6 pieces / Insulation cap 6 pieces |
Name of Manufacturer/Packer/Importer |
Kawamura Electric Industry Co., Ltd. |
Import Country |
Direct Import from Japan |
Specifications |
With AA neutral line open phase protection |
Lead Wire Length (mm) |
220 |
No. of Poles / Elements |
3P2E |
Connectable Wire (mm2) |
60 |
Outer Dimensions (mm) |
75x130x68 |
Tripper Type |
Complete electromagnetic type |
