| Type of Product | No-Fuse Breaker |
| Model No | NB223E-200 |
| Rated Breaking Capacity (kA) | 35(AC 200 V)/15(AC440V)/10(AC500V) |
| Frame (AF) | 225 |
Type of Product |
No-Fuse Breaker |
Model No |
NB223E-200 |
Rated Breaking Capacity (kA) |
35(AC 200 V)/15(AC440V)/10(AC500V) |
Frame (AF) |
225 |
Mass (Kg) |
1.8 |
Monotaro ID |
52749795 |
Rated Current (A) |
200 |
Country of Origin |
Japan |
Application |
Economic form |
Rated Insulation Voltage (V) |
AC600 |
Connection Type |
Crimp terminal (M8) |
Reverse Connection |
Impossible |
Included Components |
Terminal cover 2 pcs / Mounting screw (for iron plate) 2 pcs / Mounting screw (for wood plate) 2 pcs / Crimp terminal 6 pcs / Insulation cap 6 pcs / Hexagonal bar wrench 1 pc |
Name of Manufacturer/Packer/Importer |
Kawamura Electric Industry Co., Ltd. |
Import Country |
Direct Import from Japan |
No. of Poles / Elements |
3P3E |
Connectable Wire (mm2) |
150 |
Outer Dimensions (mm) |
105x165x68 |
Tripper Type |
Thermodynamic electromagnetic |
