Ships within 19 days
View
View
View
View
| Type of Product | No-Fuse Breaker |
| Model No | NCS2P2E30S |
| Rated Breaking Capacity (kA) | 2.5(AC 200 V)/(2.5)(AC 100/200 V) |
| Frame (AF) | 30 |
Type of Product |
No-Fuse Breaker |
Model No |
NCS2P2E30S |
Rated Breaking Capacity (kA) |
2.5(AC 200 V)/(2.5)(AC 100/200 V) |
Frame (AF) |
30 |
Mass (Kg) |
0.08 |
Rated Voltage (V) |
AC200 |
Monotaro ID |
52749156 |
Rated Current (A) |
30 |
Country of Origin |
Japan |
Application |
For smart size / home distribution board branch circuit (flat handle) |
Connection Type |
(Power side) Solderless terminal (M5) / (Load side) Plug-in terminal |
Reverse Connection |
Possible |
Included Components |
1 terminal cover |
Name of Manufacturer/Packer/Importer |
Kawamura Electric Industry Co., Ltd. |
Import Country |
Direct Import from Japan |
Specifications |
Secondary plug-in terminal type |
No. of Poles / Elements |
2P2E |
Connectable Wire (mm2) |
Φ2.6 |
Outer Dimensions (mm) |
20x70x50 |
Tripper Type |
Thermodynamic electromagnetic |
Outer Dimensions |
20x70x50 mm |
Safety Standard |
Electrical Appliance and Material Safety Law |
